LYF JIO F220B 003-01-45-051119 Flash File

LYF-F220B-003-01-45-051119_(www.ZoFind.com)1.zip
LYF JIO F220B Flashing Guide (Clean & Original Version)
Requirements

Before starting, make sure you have the correct LYF F220B firmware package, which includes:

Flash files

Qualcomm flashing tool

USB drivers

Step-by-Step Flashing Process

Extract the LYF F220B firmware package to your computer.

Install the provided USB drivers on your system.

Power off the phone and connect it to the PC while holding the * (asterisk) key.

Check Device Manager to confirm detection.
The device should appear as “Qualcomm HS-USB Diagnostics 9008”.

If this port is visible, the driver installation is successful.

Install the flashing software.
After installation, a desktop shortcut named Qflash_Tool_9.1.6 will be created.

Launch the flash tool.

Again connect the phone in boot mode (hold * key).

Click Load Content and browse to the firmware folder.

Select the file named Content.xml.

The tool will automatically detect and display the connected COM port.

Click Download Content to begin the flashing process.

Wait patiently until the process completes and shows Done / Success.

After completion, the phone will switch to download mode automatically.

Disconnect the USB cable.

Remove and reinsert the battery, then power on the device.
